After using the Keithley 236 SMU a lot in the last months without any problems, it suddenly showed the message "IOU Cal Checksum Error" and "IOU EEROM Failed" after power on. Additionally, while booting, it strangely showed a GPIB address different to the one set in the menu. It also was not possibl...
Continue reading...
Measuring Cell Capacity
As the previous repaired 6632B Power Supply is able to sink current up to 5A, I tried to characterize some Li-Ion cells by discharging with constant current, while getting the measured Voltage and Current back from the supply over GPIB using remote sensing. A fuse has been added in series for safety...
Continue reading...
ADF4351 Frequency Synthesizer
Signal Generators are usually very expensive and not easily affordable for the average user.
A cheap generator can still be built using a Wideband Frequency Synthesizer like the ADF4351, which can output frequencies from 35-4400 MHz. The internal VCO runs from 2.2 to 4.4 GHz, the range from 35-2200...
Marconi IFR 2023 / 2024 Error 508 Repair
Recently, I have bought a defective Marconi IFR 2023A signal generator from eBay. The listing said "parts or repair unit" and that the power supply is missing.
Missing power supply
The Marconi needs 5V,+/-12V and 24V, therefore I replaced the missing power supply with a Meanwell RQ-125D. The cur...
Continue reading...
